Engineering

September 14, 2026 Lead Investigator: Jackson — Group members = Jason, Jaxon, Aadyn

What if we were to create an inhaler that would provide all 13 vitamins?

Could just one breath relieve all our vitamin worries? Would it taste good if it could be made? Could we even market it? Take a peek here!

Field explored: Engineering, Biomedical engineering, Economics, Chemistry

But before we explore

MAKE YOUR PREDICTION.

Will this inhaler…

A.) Work effectively?

B.) Be dangerous?

C.) Be a global sensation?

D.) Fail miserably?

E.) Do something else?

Our predictions

-“This will become a very effective product sold globally and make us lots of money.”

-“This product will be very expensive and taste really bad”

“This product would be harmful!”

THE RULES

1.) The inhaler will contain all 13 essential vitamins

2.) The dosage will be given in two puffs

3.) The mechanism will be based on current inhalers

4.) Each vitamin will be administered in half of their daily dose per puff (for an average male).

5.) It will be administered in dispensable powder into the lungs.

WHAT WE NEED TO KNOW FIRST

How vitamins are classified

Vitamins are categorized in two main groups: fat-soluble and water-soluble

For the fat soluble vitamins, they are stored in the body’s liver, fatty tissue, and muscles. These are the vitamins that dissolve in fat. The water-soluble vitamins dissolve in water, and they are not stored in the body. Any excess leaves through urine.

Water-Soluble Vitamins

The vitamins under this category are Vitamins B1, B2, B3, B5, B6, B7, B9, B12, and Vitamin C.

The B vitamins listed above help mostly with energy metabolism and DNA repair/synthesis, and red blood cell health/formation. Though B2 assists vision.

Vitamin C acts as an antioxidant, supports immune defense, and helps make collage.

Fat-Soluble Vitamins

The vitamins that fall under this category are Vitamin A, Vitamin D, Vitamin E, and Vitamin K.

A: supports vision, immune function and skin health

D: helps the body absorb calcium

E: acts as antioxidant to protect cells from damage

K: is essential for blood clotting and bone metabolism

Daily dose of each vitamin

Added up, the total dose is 131.27mg

Vitamin C = 90mg | Vitamin B3 = 16mg | Vitamin E = 15mg | Vitamin B5 = 5mg | Vitamin B2 = 1.3mg | Vitamin B6 = 1.3mg | Vitamin B1 = 1.2mg | Vitamin A = 0.9mg | Vitamin B9 = 0.4mg | Vitamin K = 0.12mg | Vitamin B7 = 0.03mg | Vitamin D = 0.015mg | Vitamin B12 = 0.0024mg

That’s a lot of vitamins! We will see how those dosages affect our prototype later…

So…What happens?

This discussion will be organized around three main questions: Can the device hold and dispense enough material? Can all 13 vitamins reach the bloodstream in useful amounts? Would inhaling that mixture be safe?

Before we answer them, we have to discuss what kind of inhaler mechanism we are using. Our hypothetical device will store a specially formulated powder containing all 13 essential vitamins in separate, premeasured compartments. Each compartment will contain the complete mixture, rather than having the device measure each vitamin individually. Pulling a lever will make one portion ready for inhalation, and the airflow from the person’s breath will carry the powder out of the device. We are proposing three portions per day, with each containing one third of the intended daily amount of every vitamin. However, whether each portion could be delivered in a single breath would need to be tested. We are also assuming that an appropriate inhalable formulation could be developed, rather than simply crushing an ordinary multivitamin pill.

Now, we can answer the first question. Based on our initial vitamin-dose calculations, the combined daily vitamin amount is 131.27 mg. Dividing this into three portions gives approximately 43.76 mg per portion. This is a provisional estimate: we would need to verify the individual vitamin amounts and their chemical forms, and any additional formulation ingredients could increase the total powder mass. These dietary amounts also do not establish the doses needed through inhalation.

There is currently a capsule-based dry-powder inhaler used for a medicine called Bronchitol. Each capsule contains 40 mg of mannitol, and its contents are inhaled over one or two breaths. Under standardized laboratory conditions, the device delivers 32.2 mg from the inhaler, which is less than the amount loaded. This shows that handheld inhalers can dispense powder quantities in the same general range as our proposed portions. However, it does not establish that our vitamin mixture could be delivered in one breath or perform equally well. The properties of the powder and the design of the device would both matter.

As for storage, a 30-day supply at our provisional amount would contain approximately 3.94 grams of vitamins, before accounting for additional formulation ingredients. If we assume a powder bulk density of roughly 0.56 grams per milliliter, this would occupy around 7.03 mL. We will round this up to 8 mL for a rough illustration, although the actual density would need to be measured. Since 1 mL equals 1 cm³, 8 mL is equivalent to a cube measuring 2 cm on each side. That suggests the powder itself might occupy a relatively small space. However, our design would require 90 premeasured compartments for a month’s supply, and their packaging, moisture protection, and dispensing mechanism would take up additional room. Powder volume alone therefore does not establish the size of the finished device.

Now, for the second question. When a person inhales through this device, not all of the powder is guaranteed to reach the lungs. Some could remain in the device, and some could land in the mouth or throat. Later breaths might move some remaining powder, but we cannot assume they would reliably recover earlier residue or keep losses small. We would need to measure how much of each vitamin leaves the device and how much reaches the lungs.

Even reaching the lungs would not guarantee that the vitamins enter the bloodstream in useful amounts. The particles would need to dissolve in lung fluid, and the vitamins would then need to be absorbed. These processes could differ among the vitamins and their chemical forms. We therefore cannot assume that loading one third of the recommended dietary amount would supply one third of the body’s daily needs through inhalation.

Taking a sip of water afterward could help someone swallow powder remaining in their mouth, but it would not retrieve powder already in the lungs or make that powder enter the bloodstream. An added water dispenser would therefore introduce a separate oral delivery route, rather than solve the problem of lung absorption. For this investigation, we will keep the focus on the inhaled portion. Establishing its effectiveness would require formulation research and laboratory testing, followed by appropriate studies of absorption. We do not have access to those resources, so we can identify the requirements without confirming that the proposed mixture would meet them.

Now, for the last question. Multivitamins already exist in tablets, capsules, gummies, and other forms, showing that multiple vitamins can be combined in products intended to be swallowed. Mixing them does not automatically make them toxic, and making a powder does not automatically do so either. However, safety depends on their amounts, chemical forms, formulation ingredients, and how they enter the body. A mixture suitable for swallowing would not necessarily be suitable for the lungs.

We have reasons to investigate possible harm because the FDA has raised concerns that inhaled vitamin products may cause airway spasms, damage airway tissues, or produce harmful effects after absorption. This does not prove that every possible vitamin formulation would harm the lungs, but it means we cannot assume our mixture would be safe. Bronchitol’s use also does not settle this question, because its formulation and safety testing concern mannitol rather than our proposed combination of vitamins.

There are therefore two separate uncertainties: whether the mixture would provide useful vitamin absorption, and whether that exposure would be safe. Assuming that a formulation could deliver vitamins effectively would not establish its safety. Both questions would require evidence, including testing of repeated exposure if the device were intended for daily use.

Overall, existing inhalers give us a reason to explore the physical delivery concept, but we do not have enough evidence to conclude that our proposed device would safely and effectively supply all 13 vitamins. Developing it would require research into the formulation, dose consistency, particle delivery, absorption, and effects on the lungs. Our investigation identifies these challenges rather than demonstrating a finished product.

Marketability would also remain uncertain, even if an effective and safe formulation were developed. An ordinary oral multivitamin provides a useful comparison: a product costing roughly $10 for 200 daily tablets works out to about 5 cents per day, or $1.50 for a month. However, this is the retail cost of an existing oral supplement, not an estimate of the ingredients or production costs for our inhalable mixture. A specialized formulation, premeasured packaging, testing, and the inhaler itself would all affect the eventual price. We therefore cannot yet conclude that our device would be inexpensive or competitive.

The purpose of this question was to explore whether a different delivery method could help people obtain the vitamins they need, particularly in communities with limited access to adequate nutrition. For that goal, the device would need to offer a practical advantage over existing supplements, such as improved accessibility or usability for a particular group. It would also need to be affordable and easy to distribute. With further research, scientists could determine whether the idea has those advantages. For now, we have a conceivable device design and a clearer understanding of the questions that must be answered before it could become a useful product.

What surprised us?

We were surprised to learn how little space the powdered forms of all 13 vitamins take up, we thought it would be much larger than anticipated, and more expensive!

WEIRD QUESTIONS TO REAL RESEARCH

Scientists actually study…

Powder formulation and dose consistency

The safety of inhaled substances

Dry-powder inhalers and particle delivery

Drug absorption through the lungs
